Specification:
BrandXINWEIModelXW-24-12-1000WModule natureNon-isolated BUCKInput voltageDC 24V (wide pressure 18V-36V)Output voltageDC 12VOutput current85A MAX 100AOutput power1000WConversion efficiency>93%Ripple<200MVLow power consumption70MAWorking temperature-30 ° C ~ +80 ° C industrial gradeProtection functionOver-current over-voltage and short-circuit protectionInstallation line lengthNo line, current is too large, with copper busbarWiring instructionsINPUT (input positive) GND (common negative) OUPUT (output positive)Waterproof ratingIP68Shell size (L*W*H)220* 127 * 63mmWeight2.3KG

Feature:* The terminal is nickel-plated to prevent rust
* Organic silicone potting, IP68 protection, waterproof, moisture proof and dustproof* Made of high-quality aluminum profile housing, good heat conduction and heat dissipation* Internal use of the original wellhead chip, with intelligent anti-overcurrent protection, overheat protection, short circuit protection, instantaneous absorption of high voltage protection, safer use.

Applicable voltage range:
►LED car display surveillance camera, router, ADSL cat, switch, LED light digital photo frame, electronic refrigerator, portable DVD, audio, security system, portable tools, printer network equipment, control equipment, various voltage parameters Industrial equipment.


Package Included:
1 x Power converter
